| Parameter | Specification |
|---|---|
| Assembly | Bayonet |
| Type | K-Type |
| Make | Aavad |
| Configuration | Simplex |
| No. Of Wire | 2 Wire |
| Temperature Range | 0 to 600 Degrees C |
| Material Of Construction | SS 316 |
| Wire Insulation | FG/FG/SS |
| Wire Length | 2 Meter |
| Adapter | 1/4” BSP |
| Tip dia. | 6 mm |
| Tip Length | 35 mm |
| Bayonet Cap | Od 14.10 mm, ID 12.00 mm, 1 Pin Locking |
This style of thermocouple is commonly used on plastic extruders and injection molding machines. The thermocouple has a spring-loaded adjustable depth bayonet cap. When properly installed the sensing tip presses against the bottom of the hole for accurate temperature readings.
Spring-loaded adjustable depth bayonet mounting
Sensing tip presses firmly against the bottom of the drilled hole
Provides fast and accurate temperature readings
Maintains consistent contact despite vibration or thermal expansion
Quick connect and disconnect reduces maintenance time
Rugged construction for harsh plastic processing environments
Available in multiple thermocouple types (K, J, etc.)
Compatible with standard temperature controllers and indicators
Plastic extrusion machines
Injection molding machines
Extruder barrels and heater zones
Hot runner systems
Blow molding machinery
Polymer and plastic processing equipment
OEM plastic machinery installations
Replacement sensors in plastic manufacturing plants
