| Parameter | Specification |
|---|---|
| Make | Aavad |
| Model | Tw-15×7 |
| Od | 15 mm |
| Id | 7 mm |
| Moc | SS 316 |
| U Length | 50 mm |
| Process connection | 1/2″ Npt (M) |
| Instrument connection | 1/2″ Npt (F) |
Protect sensors from pressure, high flow velocity, corrosion, and vibration
Closed-end design prevents direct contact with process fluids
Allows online maintenance (sensor removal without process shutdown)
Extends the service life of RTDs and thermocouples
Maintains accurate and stable temperature measurement
Manufactured from solid bar stock or forged material
Available in threaded, flanged, and weld-in mounting styles
Compatible with RTDs and thermocouples
Materials include SS304, SS316, Inconel, Hastelloy, etc.
Suitable for high-temperature and high-pressure applications
Chemical and petrochemical plants
Oil & gas refineries
Power plants and boilers
Process pipelines (steam, gas, liquid)
Reactors, vessels, and heat exchangers
High-pressure and corrosive environments
Continuous process industries
Safety-critical temperature measurement points
