Type: K (Cr/Al)
Make: Aavad
Model: AKWD
Configuration: Duplex
Temperature range: 0 To 650℃
Material of construction: SS 316
Insulation: Compacted MgO insulation
Process connection: BSP
Process connection size: 1/2 ” (M) adjustable
Protection head: Die-Cast aluminum head with threaded cap & chain
Head protection class: IP-65
Head cable entry connection: ¾ “Et
No. of cable entry: Single
Terminal block: Nickel Plated ceramic terminal block
Od: 6 mm
The conductor materials in base metal thermocouples are made of common and inexpensive metals such as Nickel, Copper and Iron. Type E: The Type E thermocouple has a Chromel (Nickel-10% Chromium) positive leg and a Constantan (Nickel- 45% Copper) negative leg.
