| Parameter | Specification |
|---|---|
| Type | Tw-F-Tap-1.5″ |
| Make | Aavad |
| Material | SS 316 |
| Temperature range | Up To 500° C |
| Head diameter | 33 mm |
| Instrument connection | 1/2 Npt (F) |
| Process connection | Flange |
| Flange | 1.5 “Rf 150 # |
| Flange moc | SS 316 |
| U Length | 200 mm |
| Tip outer diameter (Od) | 25 mm |
| Tapper Od | 16mm |
| Taper length | 100 mm |
| Inner diameter (Id) | 7 mm |
Higher strength-to-weight ratio than straight thermowells
Superior resistance to high-frequency vibrations
Reduced risk of flow-induced resonance and fatigue failure
Reliable operation at high fluid velocities
Maintains good thermal response and measurement accuracy
Longer service life in demanding applications
Suitable for high-pressure and high-temperature processes
Compatible with RTDs and thermocouples
Available in threaded, flanged, and weld-in constructions
Manufactured from SS316, Inconel, Hastelloy, and other alloys
High-velocity process pipelines
Power plants (boilers, superheaters, reheaters)
Oil & gas and petrochemical industries
Chemical processing plants
Steam, gas, and liquid flow systems
Turbines and compressors
High-vibration industrial environments
Safety-critical temperature measurement points
