Telemetry System

Telemetry System

Magnetic FlowmeterTeflon Coated RTD Sensor
Category:

Technical Specifications

Input voltage: 24V DC, 2A

Indication: 4nos LED – Power, Network, Cloud and, Communication

Network Type: GSM, Low Power 2G ( Quad-band 850/900/1800/1900MHz )

Cloud Communication: MQTT Protocol

Communication Channel: RS-485

Data update frequency: 15 Min to 1 Day – step interval Settable from dashboard

Historic data storage: Last 3 Months

SMS Communication: Available

Daily SMS Alert: Available to maximum of 3 Users, 2 times in a day

Daily SMS Alert Time: Settable from SMS command

Instantaneous flow meter status SMS: Available

Mounting: DIN Rail Mount

Mounting Type: Snap-In

Enclosure Material: ABS (IP20)

Operating Temperature: 0 to 70 Degree C

Operating Humidity: 95% RH

Dimension (W x H x D): Width: 90 mm, Height: 105mm, Depth: 52mm

Dashboard parameters:

  • Flow
  • Positive cumulative total
  • P+N cumulative total
  • Dynamic units change as per the flow meter
  • Velocity
  • Negative cumulative total
  • Network strength & RSSI signal quality

SMS Features:

  • 1 Admin + 3 Users access
  • Auto Status Message two times in a day
  • SMS Accepted only from the authorized number
  • Date and Timestamp in the message
  • Automatic time aqasion from the network
  • Instantaneous status can be inquired

Description

  • Telemetry system you can collect flow meter data directly from RS485 Enabled flow meter and make this data into actionable insights through user-friendly cloud-based dashboarding so you can make better decisions based on facts.
  • With our cloud-based dashboarding, we can help you to bring more insights of liquid (water, chemical etc.) usage in the plants and machines in a single platform eliminating the complex multi-software, expensive software thus bringing down the IT capital costs.

Features:

❏ 1 x RS-485 port for Modbus

❏ OTA (Over The Air) Firmware support.

❏ LED Indicator provides Power, Network, Cloud, and Communication status.

❏ Keep Alive command to maintain socket connection

❏ Robust Industrial Design & Easy to install and integrate

❏ Visualize the collected data on a dashboard

❏ Analyze incoming data to derive actionable insights

❏ Store data for reporting and historical analysis

❏ Automatic reports generation with defined time intervals and to configure mails
