Threaded Diaphragm Seal with Pressure Gauge

Model: 232.50.0100 + 990.34

Make: Wika

Wetted part: SS 316 L

Movement: Stainless Steel

Case: Stainless Steel

Window: Safety Glass

Dial: White aluminium

Pointer: Black aluminium

Accuracy: 1 % of FS

Connection: 1/2″ BSP (M) Or 1/2″ NPT (M)

Fill Fluid: KN 2, Silicon Oil (Standard)

Description

Diaphragm seals are used for the protection of pressure measuring instruments in applications with difficult media. In diaphragm seal systems, the diaphragm of the diaphragm seal effects the separation of the instrument and the medium.

The pressure is transmitted to the measuring instrument via the system fill fluid which is inside the diaphragm seal system.For the implementation of demanding customer applications, there are a wide variety of designs, materials and system fill fluids available.

Data Sheet_SPIN 99.02

Download
