Description
A thermocouple is a sensor for measuring temperature that consists of two dissimilar metals that are joined together at the sensing end. Different thermocouple types (e.g. J, K, T, E, etc) use different mixtures of metals in the wire.
Wire Type Thermocouple Sensor
Wire Type Thermocouple Sensor
| Parameter | Specification |
|---|---|
| Type | K (Cr/Al) |
| Make | Aavad |
| Model | AKES |
| Configuration | Simplex |
| Total no. of wires | 2 |
| Accuracy | + /- 0.75 % |
| Temperature range | 0 To 1000 Degrees C |
| Material of construction | Inconel 600 |
| Insulation | Compacted MgO insulation |
| Cable length | 3 Meters |
| Cable insulation | FG/FG/SS |
| Od | 1.5 mm |
| Length | 200 mm |
Key Features
Simple and rugged construction
Measures a wide temperature range
Fast response to temperature changes
Self-powered (no external excitation required)
Available in multiple types (J, K, T, E, N, S, R, B)
Suitable for harsh and high-temperature environments
Cost-effective and widely used in industry
Flexible installation: probe, wire, surface, threaded, bayonet types
Compatible with standard temperature controllers and indicators
Applications
Industrial furnaces, ovens, and kilns
Plastic extrusion and injection molding machines
Boilers and power plants
Exhaust gas and engine temperature monitoring
Chemical and petrochemical processing
Food processing and industrial heating
Glass, ceramic, and metal processing
HVAC and refrigeration systems
Laboratory and testing equipment
General-purpose industrial temperature measurement
