| Parameter | Specification |
|---|---|
| Make | Aavad |
| Model | AMAG – I |
| Service | Pls specify |
| Conductivity | ≥ 10 ΜS/Cm |
| Output | 4 ‐ 20 Ma isolated, Rs – 485, Pulse |
| Display | LCD 16×4 Line 9 digit totalized flow |
| Accuracy | + / ‐ 0.5 % of reading |
| Repeatability | + / ‐ 1% |
| Process temperature | 0 °C ‐ 150 °C |
| Process pressure | Max: 10 Kg/Cm2 |
| Internal | PTFE lining |
| Electrode moc | SS 316L |
| Power supply | 230V ac |
| Response time | 0.3 Sec |
| Process connection | Asa 150 flanged MS |
| Operating temperature | 55°C |
| Electronics housing | Die-Cast aluminum, Ip 65 |
| Empty pipe detection | Yes |
| Backlight LCD | Yes |
| Velocity | 0.2 To 10 M/S |
| Measuring unit | Selectable Kg/H,M3/H,L/H,L/M,L/S,Kg/M,Kg/S |
| LINE SIZE | 15MM, 19MM, 25MM, 40MM, 50MM, 65MM, 80MM, 100MM, 125MM, 150MM, 200MM, 250MM |
|---|
Measures flow based on Faraday’s Law of Electromagnetic Induction
No moving parts – low maintenance and long service life
Highly accurate and repeatable flow measurement
Suitable for conductive liquids
Unaffected by pressure, temperature, density, or viscosity changes
Inline installation for continuous flow monitoring
Fast response time
Available with digital, analog, and communication outputs
Works well in harsh and industrial environments
Measures flow based on Faraday’s Law of Electromagnetic Induction
No moving parts – low maintenance and long service life
Highly accurate and repeatable flow measurement
Suitable for conductive liquids
Unaffected by pressure, temperature, density, or viscosity changes
Inline installation for continuous flow monitoring
Fast response time
Available with digital, analog, and communication outputs
Works well in harsh and industrial environments
