Thermocouple With Coating

Parameter	Specification
Type	K (Cr/Al)
Make	Aavad
Model	AKWS-PTFE
Configuration	Simplex
Temperature range	Up To 250℃
Material of construction	SS316
Insulation	Compacted MgO insulation
Protection head	Die-Cast aluminum head with threaded cap & chain
Head protection class	IP-65
Head cable entry connection	¾ “Et
No. of cable entry	Single
Terminal block	Nickel Plated ceramic terminal block with spring-loaded
Sensor probe	Teflon coating
Od	6 mm
Length	300 mm

Description

Teflon-coated thermocouples measure the temperature of highly corrosive acids and bases. The thermocouple measures temperatures up to 250°C, suitable for applications such as electroplating, pickling, and acid baths. The shroud is made of SS316/SS316L and then coated with Teflon (PTFE) to protect the RTD element from corrosion and thermal degradation in acidic or alkaline environments. Angle assemblies are available upon request to allow RTD installation in difficult locations. The standard clamping head is made of plastic; Stainless steel heads (SS) can also be made on request.
